2-layers RT duroid 6002 PCB Rogers 10mil Laminate

This 2-layer rigid PCB serves high-frequency microwave applications, utilizing Rogers RT/duroid 6002—a premium ceramic-filled PTFE material—to achieve outstanding signal integrity and environmental resilience.Key construction specifications are as follows:

1. PCB Specifications

2. PCB Stack-up Configuration

3. Quality & Global Compliance

This PCB adheres to industry standards for compatibility, quality, and worldwide accessibility—ideal for large-scale or cross-regional projects:

Artwork Format: Gerber RS-274-X (universal industry standard, compatible with global fabrication facilities)

Quality Standard: IPC-Class-2 compliant (meets commercial/industrial reliability requirements for microwave systems)

Availability: Globally accessible, supporting timely production across regions.

4. Rogers RT/duroid 6002 Material Introduction

Rogers RT/duroid 6002 is a high-performance microwave laminate tailored for complex high-frequency structures. As a ceramic-filled PTFE material, it combines two key advantages: low dielectric constant (for stable signal propagation) and ultra-low loss (for preserving signal strength at microwave frequencies). It also delivers excellent mechanical and electrical properties, making it reliable for multi-layer board constructions—even in demanding environments like aerospace or radar systems. Unlike some microwave materials, it balances performance with manufacturability, supporting standard PCB processing workflows.

5. RT/duroid 6002 Key Features

The material’s features are engineered to meet the strict demands of microwave applications, ensuring consistent performance across operating conditions:

6. Material Benefits

The use of RT/duroid 6002 translates to tangible advantages for the PCB, making it ideal for high-frequency critical applications:

Ultra-Low Signal Loss: Dissipation factor of 0.0012 at 10GHz ensures excellent high-frequency performance, preserving signal integrity in microwave systems.

Temperature Stability: In-plane CTE matched to copper + low thermal coefficient of Dk (12 ppm/°C) ensures consistent performance in temperature-sensitive environments (e.g., airborne radar, outdoor antennas).

Dimensional Reliability: Tight thickness control and excellent dimensional stability reduce manufacturing variability, improving production yields for high-precision microwave circuits.

Space-Grade Suitability: Low out-gassing makes it ideal for space applications (e.g., satellite GPS antennas) where outgassed materials could interfere with system performance.

Multi-Layer Compatibility: Excellent mechanical/electrical properties enable reliable use in multi-layer constructions, supporting scalable designs for complex microwave systems.

7. Typical Applications

Leveraging its high-frequency performance and environmental resilience, this PCB is well-suited for the following applications:

Radar Systems: Ground-based and airborne radar (requires low loss and temperature stability)

Antennas: Phased array antennas, Global Positioning System (GPS) antennas (needs stable Dk for signal accuracy)

Aerospace & Aviation: Commercial airline collision avoidance systems (demands reliability in harsh environments)

High-Speed Connectivity: Power backplanes, beam forming networks (requires low signal loss for high-data-rate transmission)
